How to Replace a Garage Door Cable?

Rabia Tingat • July 20, 2025

A garage door cable is a critical component in the smooth and safe operation of your garage door. When it snaps, frays, or becomes worn out, it can cause the door to become unbalanced, jammed, or even fall, leading to potential injury or property damage. Replacing a garage door cable may sound intimidating, but with the right tools, safety precautions, and instructions, it's a job many experienced DIYers can handle. In this guide, you’ll learn how to replace a garage door cable safely and effectively.


What Does a Garage Door Cable Do?


Garage door cables are responsible for lifting and lowering the door in coordination with the springs. There are typically two types of garage door systems: torsion spring systems, where the cables are wound around drums at the top corners of the door, and extension spring systems, where cables run alongside the horizontal tracks. In both cases, cables help balance the door’s weight, ensuring it opens and closes smoothly.


Signs Your Garage Door Cable Needs Replacement


Before jumping into the replacement process, it’s important to recognize the signs of a failing cable. These include:


  • The garage door hangs unevenly or gets stuck.

  • Visible fraying or corrosion on the cable.

  • The door crashes down quickly when closing.

  • Loud snapping or grinding noises during operation.

If you observe any of these symptoms, replacing your garage door cable promptly is crucial to maintain the safety and functionality of your door.


Tools and Materials Needed


Before you begin the repair, gather the following tools and safety gear:


  • Replacement cables (specific to your garage door size and type)

  • Locking pliers or C-clamps

  • Adjustable wrench

  • Winding bars (for torsion springs only)

  • Ladder

  • Safety glasses

  • Work gloves

  • Socket set or nut driver

Always double-check your garage door manual for model-specific requirements or part numbers.


Safety First


Replacing a garage door cable can be dangerous, especially if your system uses torsion springs. These springs are under high tension and can cause serious injury if handled incorrectly. If you are unsure or uncomfortable with any part of this process, it’s best to hire a professional garage door technician.


Step-by-Step Guide to Replacing Garage Door Cable


Step 1: Disconnect the Power

Start by unplugging the garage door opener or switching off the circuit breaker. This ensures the motor doesn’t activate during the repair, which could cause unexpected movement.


Step 2: Open the Garage Door Fully

If the cable hasn’t completely snapped, open the door fully to release as much tension as possible. Use C-clamps or locking pliers on the tracks just below the rollers to hold the door in place and prevent it from falling.


Step 3: Loosen Tension in the Springs (Torsion System Only)

For torsion spring systems, use winding bars to slowly unwind the tension from the springs. Insert one winding bar into the winding cone, turn slightly, and insert the second bar before removing the first. Continue this process until all tension is removed. Never attempt this step without proper tools and understanding of spring mechanics.


Step 4: Remove the Damaged Cable

Locate the cable drum (for torsion springs) or pulley system (for extension springs). Unwind or unhook the damaged cable from the drum or pulley, then detach it from the bottom bracket on the garage door panel.


Step 5: Install the New Cable

Attach the new cable to the bottom bracket first. Then, guide the cable up and around the drum or through the pulley, ensuring it sits properly in the grooves. Keep the cable tight and untwisted to prevent future alignment issues.

For torsion systems, repeat the process on both sides before rewinding the springs using your winding bars. For extension springs, reattach the spring and pulley as needed.


Step 6: Test the Tension and Balance

Once both cables are replaced and everything is reassembled, remove the C-clamps and manually lift and lower the door to check its balance and smoothness. If the door is difficult to lift or slams shut, the tension may need adjusting.


Step 7: Reconnect the Power

After confirming that the door moves freely and evenly, plug the garage door opener back in and use the wall control or remote to test its operation.


Maintenance Tips for Longer Cable Life


Garage door cables are exposed to tension, weather changes, and frequent use. To extend their life and avoid unexpected failures:


  • Inspect the cables monthly for signs of fraying or rust.

  • Apply a light lubricant to the cable and pulleys every few months.

  • Keep the garage environment clean and dry to reduce corrosion.

  • Avoid overloading your garage door with added weight (like insulation panels).

Routine maintenance can help you spot wear before it turns into a costly problem.


When to Call a Professional


While many homeowners successfully replace garage door cables on their own, certain situations call for expert help. Call a professional if:

  • You're dealing with broken torsion springs.

  • You lack proper tools like winding bars.

  • The cable has snapped while the door is closed and under full tension.

  • You notice uneven spring tension or pulley damage.

Garage doors can weigh several hundred pounds and involve high-tension parts, so always prioritize safety over savings.


Final Thoughts


Knowing how to replace a garage door cable can save you time and money—especially when you’re prepared with the right tools, safety measures, and understanding of your garage door system. Whether you’re dealing with a frayed cable or planning routine maintenance, this guide helps ensure your garage door stays safe and functional.

If you ever feel unsure during the process, remember: it’s always worth investing in professional help when your safety or your home’s security is at stake. With regular inspections and prompt repairs, your garage door cables can keep your system running smoothly for years to come.
